Solar Panel 100W - Polycrystalline
Hover to Zoom

Last Updated
25 Oct 2018
Country Origin
Indonesia
Minimum Order
1 unit

Specification of

Solar Panel 100W - Polycrystalline

ICA SOLAR IPV-100P
(100Wp Polycrystalline)

Electrical characteristics:
- Maximum Power (Pmax): 100Wp
- Power Tolerance: + 3%
- Maximum Power Supply in Pmax (Vmp): 17.60V
- Maximum Power Current in Pmax (Imp): 5.69A
- Open circuit voltage (Voc): 22.60V
- Short Circuit Current (Isc): 6.09A
- Weight (kg): 7.7kg
- Dimension Module (mm): 1020 x 670 x 30 mm
- Temperature Coefficient Pmax (% / ℃): -0.44
- Vok Temperature Coefficient (% / ℃): -0.30
- Temperature Coefficient Isc (% / ℃): +0.05
- Maximum System Voltage (VDC): 1000V (TUV); 600V (UL)
- Maximum Fusion Rating Rank (A): 15A
- Operating Temperature (℃): -40 ℃ to + 85 ℃
- Normal Operating Cell Temp (NOCT): 45 ℃ ± 2 ℃
- Application Class: Grade-A
- Cell Technology: Poly-Si
- Certification: ISO9001 / ISO14001 / OHSAS18000

Untuk keterangan lebih lanjut, silahkan download PDF ini :
