Ritar D-KT Series Tubular Traction Battery
Tubular Traction Battery with Low Antimony Alloy and Stable Welded Connections.
The Ritar D-KT Series is a range of 2V industrial batteries designed for high performance and minimal maintenance. This series covers a capacity range from 330Ah to 620Ah (C5). The primary advantage of the D-KT series is the use of low antimony alloy, which significantly reduces water loss, thereby lowering maintenance costs and frequency.
Structurally, it employs tubular positive plates die-cast under high pressure (10MPa) and features a Lead Cast Head Welded Connection Strip method. This connection method ensures excellent current stability and reliable inter-cell connections, making it an ideal solution for forklifts and heavy-duty material handling equipment.
Key Features and Manufacturing Technology
Technical advantages of the D-KT series based on official specifications:
- Low Antimony Alloy: The low antimony alloy design reduces water evaporation, resulting in longer maintenance intervals and greater cost efficiency.
- Stable Welded Connection: Adopts a lead cast head welded connection strip method that is highly stable and reliable.
- Die-Cast Tubular Plates: Positive tubular plates are die-cast under 10MPa pressure, producing a dense grid surface and strong corrosion resistance.
- Pure Material: Uses 1# electrolytic lead with purity up to 99.994%.
- High Safety: Equipped with an explosion-proof exhaust plug offering excellent air permeability.
- Certifications: Passed ISO9001, ISO14001, and ISO45001 certifications.
Complete Parameters Table (Product Parameters)
Below are the physical dimension and capacity (C5) specifications for models in the Ritar D-KT series:
| Model |
Volt (V) |
Capacity C5 (Ah) |
Length (mm) |
Width (mm) |
Height (mm) |
Total Height (mm) |
Terminal |
| D-330KT | 2 | 330 | 180 | 138 | 415 | 460 | D1 |
| D-385KT | 2 | 385 | 180 | 138 | 415 | 460 | D1 |
| D-440KT | 2 | 440 | 180 | 176 | 415 | 460 | D1 |
| D-440KT(A) | 2 | 420 | 207 | 160 | 330 | 370 | D1 |
| D-440KT(B) | 2 | 440 | 125 | 158 | 460 | 500 | D1 |
| D-560KT | 2 | 560 | 164 | 146 | 530 | 580 | D1 |
| D-620KT | 2 | 620 | 177 | 160 | 470 | 510 | D1 |
| D-560KT(A) | 2 | 560 | 125 | 158 | 550 | 590 | D1 |
| D350KT | 2 | 350 | 93 | 158 | 485 | 525 | D1 |
| D450KT | 2 | 450 | 93 | 158 | 595 | 635 | D1 |
| D500KT | 2 | 500 | 93 | 158 | 665 | 705 | D1 |
About Distributor UPS ICA
Distributor UPS ICA located in Cikarang is a trusted partner for industrial traction battery needs. We provide original Ritar D-KT Series with manufacturer quality assurance. Our technical team is ready to assist you in selecting the right specifications for your forklift fleet, providing responsive after-sales service, and ensuring safe delivery throughout Indonesia.
Enhance operational efficiency with low-maintenance batteries and stable connections. Contact Distributor UPS ICA now for Ritar D-KT Series offers. Check other products in the UPS & Traction Battery category or get technical information on our UPS Battery Blog.
